6-4 250cx Series Maternal/Fetal Monitor Revision C

2036947-001

Parts List, Drawings, and Replacement: Field-Replaceable Units (FRUs)

Field-Replaceable Units (FRUs)

FRU List

The following table offers details of each of the corresponding bubble numbers that

appear on the exploded engineering-assembly drawings.

Bubble

Number

Part Number Description Comments

2-5,7-11 2025177-034 Front/Rear Panel Labels FRU (Eng)

2-5,7-11 2025177-035 Front/Rear Panel Labels FRU (INT)

1 2025177-030 Top Cover FRU

N/A 2025177-019 Misc Cable FRU Does not include front end patient

cables

N/A 2025177-003 Speaker FRU

3 2025177-033 DSP Board FRU

6 2025177-007 Dual Ultrasound Board FRU

7 2025177-008 FECG/UA w/MECG Board FRU

7 2025177-009 Isolated Power Supply Board FRU

9 2025177-010 SpO

Carrier Board w/Nellcor Ox FRU

9 2025177-011 SpO

Carrier Board w/Masimo Ox FRU

9 2025177-012 SpO

carrier Board w/Ohmeda Ox FRU

N/A 2025177-020 Pneumatics Board FRU

2 2025177-029 MECG Board FRU

5 2025177-006 Fan FRU

3 2025177-013 Front-end Mother Board. FRU

4 2025177-016 Comm Board w/plate FRU

2 2025177-028 Main Power Supply FRU

4 2025177-037 Main Board FRU

10 2025177-036 Chassis Assembly DRU Depot repair only, do not ship to FE.

Customers out of warranty may

purchase

28 2025177-027 Power Switch Assembly

26 2025177-032 Display FRU
