3-4 250cx Series Maternal/Fetal Monitor Revision C

2036947-001

Installation: Connections

J101 Connector (Model 340 Telemetry System Interface)

NOTE: For additional information,

refer to the Model 340 Service Manual,

P/N 2006920-001.

This connector is for future interfacing to the receiver of a Corometrics Model 340

Telemetry System.

A telemetry indicator is displayed beneath the FHR1 mode field:

 you connect a telemetry receiver to the 250cx Series Monitor; and

 the receiver detects an active FECG, MECG, US, TOCO, or IUP mode from the

associated transmitter.

NOTE: The monitor, receiver, and transmitter must all be turned on.

NOTE: When any telemetry mode is detected (US, FECG, MECG, TOCO, or IUP), all

equivalent front panel modes (US, US2, FECG, MECG, TOCO, or IUP) are

ignored. You cannot “mix and match” telemetry and monitor modes.

The telemetry connected annotation is printed on the bottom line of the top grid

of the strip chart paper:

 upon commencement of telemetry monitoring; and

 every 30 minutes along with the modes.

The telemetry disconnected annotation is printed on the strip chart paper if:

 you unplug the telemetry receiver from the 250cx Series Monitor;

 you turn off the receiver;

 you turn off the transmitter; or

 the receiver does not detect any active mode information from the transmitter.

J102 Connector (Spectra 400 Analog Interface)

This Centronics-type connector is designed for interfacing to a Corometrics Spectra

400 Central Surveillance and Alert System or other compatible analog central

information system. This connector is often referred to as the Analog Interface

Connector. For detailed information about connecting to a Spectra 400 System, refer

to the “Systems Pre-Installation Manual” (P/N 1279AA).

J103 Connector (Model 2116B Data Entry Interface)

This connector is specifically designed for connecting to an optional Corometrics

Model 2116B Data-Entry/Clinical-Notes Keyboard. For detailed information about

connecting the Model 2116B to the monitor, refer to the “Model 2116B Product

Manual” (P/N 1252BA).
