Revision C 250cx Series Maternal/Fetal Monitor 5-5

2036947-001

Troubleshooting: Diagnostic Control Screen

Diagnostic Control Screen

The Diagnostic Control screen, as shown below, is used to perform the following

diagnostic self-tests:

 Recorder Calibration test;

 Status Relay softkey tests Nurse Call Interface relay;

 CPU software version number;

 DSP software version number;

 Monitor Run Time;

 Recorder run time (Rec Time);

 Clear softkey sets run time and record to 0:00

 Main Board SW1 switch setting summary;

 Softkey to access J102 test screen; and

 Softkey to access the NIBP Calibration screen.

Diagnostic Control

J102

Exit

Diagnostic Control

Recorder Calibration: Off

Status Relay: Off

NIBP Cal

CPU V4.30 X DSP 03.07

Clear

Run Time:

Rec Time:

SW1: 10111110

MECG MSpO

NIBP

366:29:49

0:18:11
