2-16 250cx Series Maternal/Fetal Monitor Revision C
2036947-001
Equipment Overview: DINAMAP® Models PRO Series 100-400 and ProCare
DINAMAP
®
Models PRO Series 100-400 and ProCare
All of the above DINAMAP Monitors can be interfaced to a 250cx Series Monitor
to provide a printout of NIBP values on the strip chart paper.
ILC-1926
An ILC-1926 is required to interface with the DINAMAP PRO Series and ProCare
Monitors.
Centricity Perinatal (QS)
Through this interface, the 250cx Series Monitor outputs MHR data, FHR data, and
UA data to a central information system such as a Centricity Perinatal (QS).
Annotations made at the central station can be optionally printed on the strip chart
paper of the 250cx Series Monitor as summarized below (if the central station has
the capability to send the command):
Each message is preceded by a computer icon ( ).
Messages are restricted to a maximum length of
50 characters.
Lower-case letters are converted to upper-case letters.
Non-standard characters are replaced with spaces.
The 250cx Series Monitor can be configured with the remote annotation capability
enabled (1371/Notes mode) or disabled (1371 mode). The following is an example of
a remote message sent to a 250cx Series Monitor from a central information system
using this serial communications protocol.
<SPW> AVERAGE VARIABILITY
To connect a central information system:
1. Obtain an appropriate interface cable: connect one end to an available
RS-232C
connector (J109, J110, or J111) on the 250cx Series Monitor; connect the other
end to the wallplate wired to the central information system. For a Centricity
Perinatal (QS): the interface cable is catalog number (REF) 1558AAO (10') or
1558BAO (20'); the corresponding wallplate connector is labeled
RS-232
COMMUNICATIONS
.
2. Access the Communications Setup service mode screen and set the baudrate
and mode for the appropriate port to 1200 bps and either the 1371 or 1371/Notes
mode, respectively; then exit the service mode screens.
Exergen
®
TAT-5000™
Exergen
®
TAT-5000™ provides maternal temperature as a printout and vital signs
history. Exergen
®
TAT-5000™ is only available on J109 and J110.
