Revision C 250cx Series Maternal/Fetal Monitor 2-15
2036947-001
Equipment Overview: Peripheral Components
1. Using interface cable, connect one end to an available
RS-232C port (J109 or
J111 only) on the 250cx Series Monitor; connect the other end to the
Serial
Communications
port on the pulse oximeter.
2. Access the Communications Setup service mode screen and set the mode to
Nellcor for the appropriate port. Using the manufacturer’s instructions for use for
the external monitor, determine the baudrate setting for the 250cx Series monitor.
Store settings to hospital defaults and restart the monitor.
3. Access the General Setup screen and choose the time interval for printing the
MSpO
2
values on the strip chart paper. Refer to “Setup” on page 3-9 for more
detailed information.
4. Ensure the NPB N-200 is set to the Beat-to-Beat mode.
Nellcor Puritan Bennett Model N-400 Fetal Pulse Oximeter
NOTE: The Model N-400 monitor
is not available in all countries.
Through this interface, FSpO
2
readings provided by an NPB Model N-400 are
printed at selected intervals on the strip chart paper of the 250cx Series Monitor.
When the recorder is on, each reading is printed in the annotation area between the
top and bottom grids. A filled diamond marker, above the measured values, marks
the time of the reading and identifies the data source as an external device. The
following is an example annotation:
FSpO
2
45%
In addition, the FSpO
2
trend can be optionally printed on the bottom grid of the strip
chart paper; the trend is printed as a beaded trace ( ).
NOTE: Your Nellcor N-400 must be at communications software version
4.2.0.02 or later. Consult your Nellcor product documentation,
or contact your Nellcor representative if you are not certain of
the version.
To connect the Model N-400:
1. Using interface cable, connect one end to an available
RS-232C port (J109,
J110, or J111) on the 250cx Series Monitor; connect the other end to the
Serial
Communications
port on the pulse oximeter.
2. Access the
Communications Setup
service mode screen and set the mode to Nellcor
for the appropriate port. Using the manufacturer’s instructions for use for the
external monitor, determine the baudrate setting for the 250cx Series monitor.
Then exit the service mode screens.
3. Access the General Setup screen, then: choose the time interval for printing the
FSpO
2
values on the strip chart paper; and enable/disable trending of FSpO
2
on
the bottom grid of the strip chart paper. Refer to “Setup” on page 3-9 for more
information.
4. Ensure the NPB N-400 is set to the Beat-to-Beat mode.
