DigitalFlow™ GF868 Programming Manual (1-Channel) 107
Appendix C. Programming with PanaView
C.5.6b Saving a New Site to the Meter
To save a new site to the meter:
1. Select the radio button for New and click on the Save Site to Meter button.
2. A window opens similar to Figure 32. Enter the desired name, and click [OK].
Figure 32: Site Name Entry Window
3. The Site File Selection window (Figure 31 on page 106) opens. Highlight a site with the desired settings, and click
[Open]. PanaView saves the site in the meter with the new name and the desired settings.
C.5.6c Saving a Site to the PC
To save a site to the PC:
1. Highlight the desired site in the left pane. (See Figure 30 on page 106.)
2. Click Save Site to PC. A window opens similar to Figure 29 on page 105.
3. Enter the desired site name and click [Save]. PanaView saves the site in the PanaView folder unless otherwise
specified.
Note: If you have created a site on the meter after opening the Site File Operations window, you must close and
reopen the window to click on the new site.
C.5.6d Clearing a Site from the Meter
To clear a site from the meter:
1. Highlight the site in the left pane. (See Figure 30 on page 106.)
2. Click Clear Site From Meter.
3. The program asks for confirmation. Click [OK]. The meter deletes the designated file.
