Appendix C. Programming with PanaView
108 DigitalFlow™ GF868 Programming Manual (1-Channel)
C.5.6e Saving a Site in Text Form
To store the data from a site file as a text file for display or printout:
1. Highlight the site in the left pane. (See Figure 30 on page 106.)
2. Click Save Site Print to PC.
3. The Site File Selection window (Figure 31 on page 106) opens. Enter the desired site name (now with a .prt suffix)
and click [Save]. PanaView displays a text version of the site, as shown in Figure 33.
Figure 33: Printout of Site File
4. Click
[Close] once to close the Site File Operations window, and a second time to close the Properties window and
return to the Meter Browser.
