GE PROPRIETARY TO GE
D
IRECTION 5308917-100, REVISION 8 LOGIQ P3 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-57
3) Remove SATA cable from Hard disk drive assembly Refer Figure 8-64 on page 8-57
Figure 8-64 Removing SATA cable
8-5-1-5 Mounting procedure
Install the new parts in the reverse order of removal.
8-5-1-6 Functional Checkout Procedure
See
Section
Functional Test Debrief Script
4-3-1 Power On/Boot Up
Service Manual Direction 5308917-100, Section 8-5-1. Equipment passes all required
tests and is ready for use.
4-3-2 Power Off/ Shutdown
To Next Page
