GE HEALTHCARE
DIRECTION 5245279, REVISION 3 LOGIQ™ P6/P6 PRO SERVICE MANUAL
Section 8-2 - DISASSEMBLY/RE-ASSEMBLY 8 - 49
8-2-15 Front Cover
8-2-15-1 Tools
• Common philips screwdrivers
8-2-15-2 Preparations
• Shut down the system and switch off the main breaker.
8-2-15-3 Removal procedure
1.) Remove the Left and Right side covers. Refer to the 8-2-14 "Right or Left Side Cover" on page 8-47
2.) Remove the dummy left and right covers. Refer to the Figure 8-88.
3.) Remove the two screws on each side of the back of the front cover.
Figure 8-88 Screws of Dummy Cover
Figure 8-89 Screws of the front cover
To Next Page
