GE LOGIQ V2

System Data
LOGIQ V2/LOGIQ V1 – User Guide 3-35
Direction 5610736-100 Rev. 9
Table 3-5: Measurements and Calculations
B-Mode
• Depth and Distance
• Circumference and Area (Ellipse/Trace)
• Volume (Ellipsoid)
• Angle between 2 Lines
• % Stenosis (Area or Diameter)
M-Mode
• M Depth and Distance
• Time
• Slope
• Heart Rate
Doppler Measurements/Calculations
• Velocity
• Time
• A/B Ratio (Velocities/Frequency Ratio)
• PS (Peak Systole)
• ED (End Diastole)
• PS/ED (PS/ED Ratio)
• ED/PS (ED/PS Ratio)
• AT (Acceleration Time)
• Accel (Acceleration)
• TAMAX (Time Averaged Maximum Velocity)
• Volume Flow [TAMEAN and Vessel Area]
• Heart Rate
• PI (Pulsatility Index)
• RI (Resistivity Index)
Vascular Measurements/Calculations
• Carotid, Vertebral, Subclavian Measurements,
Auto IMT
• Summary Reports
Obstetrics Measurements/Calculations
• Gestational Age Calculation
• EFW Calculation
• Calculations and Ratios
• Measurements/Calculations
• Fetal Graphical Trending
• Growth Percentiles
• Multi-Gestational Calculation
• Fetal Qualitative Description (Anatomical Survey)
• Fetal Environmental Description (Biophysical
profile)
• Programmable OB Tables
• Over 20 selectable OB Calcs
• Expanded Worksheets
Gynecology Measurements/Calculations
• Right/Left Ovary Length, Width, Height
• Uterus Length, Width, Height
• Cervix Length, Trace
• Ovarian Volume
• ENDO (Endometrial thickness)
• Ovarian/Uterine RI
• Summary Report
Urology Calculation
• Bladder, Prostate, Renal, Generic Volume
Measurements
• Post-Void Bladder Volume
Cardiology Measurements/Calculations
• Cardiology Measurements and Calculations
• Summary Worksheet
• Summary Report
Table 3-6: Probes
• 4C-RS (Applications: Abdomen, Obstetrics,
Vascular, Gynecology, Urology, Mulsculoskeletal,
Biopsy)
• 8C-RS (Applications: Cardiac, Transcranial,
Pediatrics and Neonatal, Musculoskeletal)
• 3Sc-RS (Applications: Abdomen, Cardiac,
Transcranial, Biopsy)
• 12L-RS (Applications: Vascular, Musculoskeletal,
Small Parts, Pediatrics and Neonatal, Biopsy
• L6-12-RS (Applications: Vascular,
Musculoskeletal, Small Parts, Pediatrics and
Neonatal, Biopsy)
• LK760-RS (Applications: Musculoskeletal)
• E8C-RS (Applications: Obstetrics, Gynecology,
Transvaginal, Transrectal, Biopsy, Urological)
Table 3-7: Inputs and Outputs Signal
External Inputs and Outputs
• 1 dedicated Isolated USB printer port
• 2 general USB ports
• Ethernet port
• HDMI port
• VGA output through an external video adapter from
HDMI
