GE LOGIQ V2

Probe Discussion
LOGIQ V2/LOGIQ V1 – User Guide 5-21
Direction 5610736-100 Rev. 9
Features
NOTE: Not all features, products, probes or peripherals described in
this document may be available or cleared for sale in all
markets. Please contact your local GE Ultrasound
representative to get the latest information.
Specifications
Table 5-7: Probe Features
Probe
Application
4C-RS 8C-RS 3Sc-RS L6-12-RS E8C-RS
LK760-
RS
12L-RS
LOGIQ View X X X X X X X
Easy 3D X X X X X X X
CWD X
TVI/TVD X
CrossXBeam X X X X X X
SRI-HD X X X X X X X
Scan Coach X X X X X X
Virtual Convex X X X X
B/Harmonic X X X X X X X
PWD X X X X X X X
M Mode X X X X X X X
AMM X X X
CMM X
Needle X X
CF X X X X X X X
PDI X X X X X X X
Note: That LK760-RS probe supports PWD, PDI and CF is only available on R1.1.x software.
Table 5-8: Probe Specifications
Probe
Designation
Center Image
Frequency (MHz)
Frequency Range
(MHz)
Doppler Frequency
Range (MHz)
4C-RS 3.10 2.00 ~ 5.00 2.00 ~ 3.60
3Sc-RS 2.75 2.00 ~ 4.00 1.70 ~ 3.30
