GE LOGIQ V2

Using Onboard Help
6-38 LOGIQ V2/LOGIQ V1 – User Guide
Direction 5610736-100
Rev. 9
Peripheral Connection (continued)
Software Version
Figure 6-27. Software Version
1/2 Software version and series number
information is helpful when
communicating with a GE service
center or field engineer. Press Utility,
and then select System tab. Next click
on the About tab. The software
version is now displayed.
2/2 Select the Admin tab in Utility to
display the serial number for the
device.
