Device Labels
LOGIQ V2/LOGIQ V1 – User Guide 4-33
Direction 5610736-100 Rev. 9
AC adapter for LOGIQ V2/LOGIQ
V1
AC adapter
No-Load power consumption AC adapter
Average Active Efficiency AC adapter
Test Battery
Rechargeable Smart Battery
Pack
Battery
Only for LOGIQ V2/LOGIQ V1
system
Battery
Output AC adapter
Type/Class Label Used to indicate the degree of
safety or protection.
IP Code (IPX8)
IPX8: FSU-1000, MKF 2-MED
GP26
Indicates the degree of protection
provided by the enclosure per
IEC60 529.
Bottom of footswitch
Authorized European
Representative address.
Bottom panel
United States only
Prescription Requirement label.
CAUTION: United States law
restricts this device to sale or use
by, or on the order of a physician.
Bottom panel
Type BF Applied Part (man in the
box) symbol is in accordance
with IEC 60878-02-03.
Beside the probe connector
General Warning. Various
Table 4-6: Label Icons (Continued)
Label/Icon Purpose/Meaning Location
