Performing an Exam
2-4 LOGIQ V2/LOGIQ V1 – User Guide
Direction 5610736-100
Rev. 9
Edge Enhance No Edge Enhance brings out subtle tissue differences and boundaries
by enhancing the gray scale differences corresponding to the
edges of structures.
Rotation No You can flip the image up/down.
CAUTION: When reading an rotated image, be careful to observe
the probe orientation to avoid possible confusion over scan
direction or left/right image reversal.
Rejection No Selects a level below which echoes will not be amplified (an echo
must have a certain minimum amplitude before it will be
processed).
Suppression No Suppresses the noise in the image.
SRI-HD (Option) No SRI-HD (Speckle Reduction Imaging High Definition) is an adaptive
algorithm to reduce the speckle in the ultrasound image.
LOGIQ View
(Option)
No LOGIQ View provides the ability to construct and view a static 2D
image which is wider than the field of view of a given transducer.
This feature allows viewing and measurements of anatomy that is
larger than what would fit in a single image. Examples include
scanning of vascular structures and connective tissues in the arms
and legs.
LOGIQ View constructs the extended image from individual image
frames as the operator slides the transducer along the surface of
the skin in the direction of the scan plane. The quality of the
resulting image is somewhat user-dependent and requires some
additional skill and practice to develop proper technique and
become fully proficient.
LOGIQ View is only available in B mode.
Table 2-1: B-Mode Controls (Continued)
Control Bioeffect Description/Benefit
