– 67 –
Electronic Oven Control
Overview
The Electronic Oven Control system consists of the logic board, power supply board, relay board, oven
controls, oven sensor, and door lock assembly.
Caution: Certain components are electrically HOT when voltage is connected to range.
Bake, broil, and convection units can be on at the same time.
Bake, broil, and convection units can operate independently or simultaneously during preheat. There are
ve elements in each oven that can operate in any combination. There can be several minutes of off time
between bake and broil unit operation after preheat.
ELEMENTS FANS
Conv Conv Cooling Cooling Oven Latch
Mode Bake 1 Bake 2 Broil 1 Broil 2 Conv 1 Conv 2 CW CCW Lo Hi Lamp Motor
Preheat
(Bake,
Conv. Bake, Cycling Cycling Cycling Cycling Off Cycling Off On
Conv. Roast On
Bake Off Off (above
Conv. Bake Off Off Cycling Cycling Cycling Cycling 200°F) Off On Off
Broil Hi Off Off
Broil Lo Off Off Cycling Cycling
Conv. Broil Off Off Cycling Cycling
Proof Off Off
Off Off Off
Cycling
Clean Cycling Cycling Cycling Cycling On Off On
COMPONENT OPERATION DURING GIVEN MODE
