GE Monogram ZDP486ND User Manual

– 84 –
Prorange Sales Demo Kit
A sales demo kit is available that activates all lights
and control displays. (Pub Number 24-M488.)
Kit Wiring Diagram
Note: 120 VAC applied to L1 and L2 (note jumper
between L2-N)
Optional Black Knob Kits
Optional black knob kits are available for ranges and
rangetops.
Range Models Part Number
ZDP304N/LPSS WB03K10268
ZDP366N/LPSS WB03K10269
ZDP364N/LRPSS WB03K10270
ZDP364N/LDPSS WB03K10271
ZDP484N/LGPSS WB03K10272
ZDP486N/LRPSS WB03K10273
ZDP486N/LDPSS WB03K10274
Rangetop Models Part Number
ZGU366N/LPSS WB03K10275
ZGU364N/LRPSS WB03K10276
ZGU364N/LDPSS WB03K10277
ZGU484N/LGPSS WB03K10278
ZGU486N/LRPSS WB03K10279
ZGU486N/LDPSS WB03K10280
Black Oven Knob Shown
Optional Accessories
Optional Backsplashback Kits
Two optional backsplash kits are available for
ranges and rangetops:
12-inch tall stainless steel backsplash•
36-inch tall backsplash equipped with a shelf •
that can adjust from 30” to 36” height.
Note: All backsplashes attach to the back wall and
not the range or rangetop itself.
12-inch high backsplash available:
ZX12B48PSS, for 48 in. wide units•
ZX12B36PSS, for 36 in. wide units•
ZX12B30PSS, for 30 in. wide units•
30-to 36 inch adjustable height backsplash with
shelf available:
ZXADJB48PSS, for 48 in. wide units•
ZXADJB36PSS, for 36 in. wide units•
ZXADJB30PSS, for 30 in. wide units•
