– 80 –
120 VAC INPUT
C
C
L1
33
Ω
N
RC
W
240 VAC OUTPUT
TRANSFORMER
188
Ω
W
G
1
2
L2
IGNITER
GLOW BAR
V
N
N
W
GRILL VALVE
SWITCHES
SAFETY
VALVE
W
W
3.40 - 3.60 amps
45 - 400
Ω
Ω1
3A
16A
Grill
120 VAC INPUT
C
C
L1
33
Ω
N
RC
W
240 VAC OUTPUT
TRANSFORMER
188
Ω
W
G
1
2
L2
IGNITER
GLOW BAR
SAFETY
VALVE
W
W
3.40 - 3.60 amps
45 - 400
Ω
Ω1
THERMOSTAT
B
R
R
N
W
Griddle
