GE Multilin F650 Digital Bay Controller B-25
APPENDIX B B.1 MODBUS PROTOCOL FOR 650
B
ADDRESS Bit Name Format Step Mode Length Miscellaneous
Estado Tarjeta G - Board G Status
0x00B1 0x2000 BOARD G STATUS F001 R 1
LEDS HMI (16 elementos) - HMI Leds
0x00D1 0x4000 READY LED F001 R 1
0x00D1 0x8000 LED 1 F001 R 1
0x00D1 0x0001 LED 2 F001 R 1
0x00D1 0x0002 LED 3 F001 R 1
0x00D1 0x0004 LED 4 F001 R 1
0x00D1 0x0008 LED 5 F001 R 1
0x00D1 0x0010 LED 6 F001 R 1
0x00D1 0x0020 LED 7 F001 R 1
0x00D1 0x0040 LED 8 F001 R 1
0x00D1 0x0080 LED 9 F001 R 1
0x00D2 0x0100 LED 10 F001 R 1
0x00D2 0x0200 LED 11 F001 R 1
0x00D2 0x0400 LED 12 F001 R 1
0x00D2 0x0800 LED 13 F001 R 1
0x00D2 0x1000 LED 14 F001 R 1
0x00D2 0x2000 LED 15 F001 R 1
Teclas HMI - HMI Keys
0x00D2 0x4000 I Key F001 R 1
0x00D2 0x8000 O Key F001 R 1
0x00D2 0x0001 * Key F001 R 1
0x00D2 0x0002 F1 Key F001 R 1
0x00D2 0x0004 F2 Key F001 R 1
0x00D2 0x0008 LOCAL OPERATION MODE F001 R 1
0x00D2 0x0010 OPERATIONS BLOCKED F001 R 1
Estados Internos - Internal States
0x00D2 0x0020 DSP COMM ERROR F001 R 1
0x00D2 0x0040 MAGNETIC MODULE ERROR F001 R 1
Entrada Reset Leds (configurable) -Led reset Input
0x00D2 0x0080 LED RESET INPUT F001 R 1
