B-26 F650 Digital Bay Controller GE Multilin
B.1 MODBUS PROTOCOL FOR 650 APPENDIX B
B
ADDRESS Bit Name Format Step Mode Length Miscellaneous
Sobrecorriente instantanea de fases nivel alto - Phase IOC High
0x00F2 0x0080 PH IOC1 HIGH A BLK F001 R 1
0x00F3 0x0100 PH IOC1 HIGH B BLK F001 R 1
0x00F3 0x0200 PH IOC1 HIGH C BLK F001 R 1
0x00F3 0x0400 PH IOC1 HIGH A PKP F001 R 1
0x00F3 0x0800 PH IOC1 HIGH A OP F001 R 1
0x00F3 0x1000 PH IOC1 HIGH B PKP F001 R 1
0x00F3 0x2000 PH IOC1 HIGH B OP F001 R 1
0x00F3 0x4000 PH IOC1 HIGH C PKP F001 R 1
0x00F3 0x8000 PH IOC1 HIGH C OP F001 R 1
0x00F3 0x0001 PH IOC1 HIGH PKP F001 R 1
0x00F3 0x0002 PH IOC1 HIGH OP F001 R 1
0x00F8 0x0004 PH IOC2 HIGH A BLK F001 R 1
0x00F8 0x0008 PH IOC2 HIGH B BLK F001 R 1
0x00F8 0x0010 PH IOC2 HIGH C BLK F001 R 1
0x00F8 0x0020 PH IOC2 HIGH A PKP F001 R 1
0x00F8 0x0040 PH IOC2 HIGH A OP F001 R 1
0x00F8 0x0080 PH IOC2 HIGH B PKP F001 R 1
0x00F9 0x0100 PH IOC2 HIGH B OP F001 R 1
0x00F9 0x0200 PH IOC2 HIGH C PKP F001 R 1
0x00F9 0x0400 PH IOC2 HIGH C OP F001 R 1
0x00F9 0x0800 PH IOC2 HIGH PKP F001 R 1
0x00F9 0x1000 PH IOC2 HIGH OP F001 R 1
0x00FE 0x2000 PH IOC3 HIGH A BLK F001 R 1
0x00FE 0x4000 PH IOC3 HIGH B BLK F001 R 1
0x00FE 0x8000 PH IOC3 HIGH C BLK F001 R 1
0x00FE 0x0001 PH IOC3 HIGH A PKP F001 R 1
0x00FE 0x0002 PH IOC3 HIGH A OP F001 R 1
0x00FE 0x0004 PH IOC3 HIGH B PKP F001 R 1
0x00FE 0x0008 PH IOC3 HIGH B OP F001 R 1
0x00FE 0x0010 PH IOC3 HIGH C PKP F001 R 1
0x00FE 0x0020 PH IOC3 HIGH C OP F001 R 1
0x00FE 0x0040 PH IOC3 HIGH PKP F001 R 1
0x00FE 0x0080 PH IOC3 HIGH OP F001 R 1
