GE Multilin W650 - Page 328

7-16 W650 Wind Generator Protection System GEK-113032A
7.2 IEC 61850 PROFILE FOR W650 7 IEC 61850 PROTOCOL
7
c) PTOF (OVERFREQUENCY)
4 OVERFREQUENCY NODES
d) PTOV (OVERVOLTAGE)
PHSPTOV: 3 PHASE OVERVOLTAGE.
PTOF CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
PTOF OverFrequency
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status Information
Str geGeneralACD Start M TOF PKP
Op geGeneralACD Operate M TOF OP
Blk geGeneralACT Block P TOF BLK
Settings
StrVal geFloatASG Start value (frequency) O Pickup Level (20-65)
BlkVal geIntASG Voltage Block Value O Minimun Voltage (30-500)
OpDlTmms GeFloatASG Operate Delay Time O Trip Delay (0-900)
RsDlTmms geFloatASG Reset Delay Time O Reset Delay (0-900)
PTOFEna geSPG Function TOF enable P Function (Enable,Disable)
PTOV CLASS
Attribute
Name
Attr.
Type
Explanation M/O Notes
PTOV Overvoltage
DATA
Common Logical Node Information
Mod geModINC Mode M
Beh geINS Behaviour M
Health geINS Health M
NamPlt geLPL Name plate M
Status Information
Str gePhsACD Start M TOV PKP
Op gePhsACT Operate O TOV OP
Blk geGeneralACT Block P TOV BLK
Settings
StrVal geIntASG Start Value O Pickup Level (3 – 850)
OpDlTmms geFloatASG Operate Delay Time O Trip Delay ( 0 – 900 )
RsDlTmms GeFloatASG Reset Delay Time O Reset Delay ( 0 – 900 )
OpMod GeING_6 Logic Mode P Logic ( Any, two, all phases )
PTOVEna geSPG Function TOV enable P Function
