GE P444

P44x/EN IT/H
b6 Introductio
n
(IT) 1
-12
MiCOM P40 Agile P442, P444
Distance Protection P444 P444 **
Nominal auxiliary voltage
24-54 Vdc 7
48-125 Vdc (40-100 Vac) 8
110-250 Vdc (100-240 Vac) 9
In/Vn rating
Dual rated CT (1 & 5A : 100 - 120V) 1
Module Sum (∑1A / PXDB) 5
C
Hardware options
Standard version 1
IRIG-B input 2
Fibre optic converter (IEC60870-5-103) 3
IRIG-B input and Fibre optic converter (IEC60870-5-103) 4
Single Ethernet 100Mbit/s 6
Rear Comms + InterMiCOM 7
Rear Comms + IRIB-B + InterMiCOM 8
Single Ethernet (100Mbit/s) plus IRIG-B (Modulated) Software version '31' and later (Suffix J) A
Single Ethernet (100Mbit/s) plus IRIG-B (Un-modulated) Software version '31' and later (Suffix J) B
IRIG-B (Un-modulated) (Software version '31' and later) C
InterMiCOM + Courier Rear Port * E
InterMiCOM + Courier Rear Port + IRIG-B modulated
* F
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Modulated IRIG-B G
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Un-modulated IRIG-B H
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Modulated IRIG-B J
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Un-modulated IRIG-B K
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Modulated IRIG-B L
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Un-modulated IRIG-B M
Redundant Ethernet PRP/HSR, 2 fibre ports + Modulated IRIG-B N
Redundant Ethernet PRP/HSR, 2 fibre ports + Unmodulated IRIG-B P
* NB: Options available with Software version 45 & later (Design Suffix K)
Models
1 & 3 Pole tripping/reclosing with 24 inputs & 32 outputs B
1 & 3 Pole tripping/reclosing with 24 inputs & 34 ouputs (12 high break) C
1 & 3 Pole tripping/reclosing with 24 inputs & 32 outputs (4 fast output contacts) D
1 & 3 Pole tripping/reclosing with 24 inputs & 32 outputs (8 fast output contacts) E
1 & 3 Pole tripping/reclosing with 24 inputs & 46 outputs J
1 & 3 Pole tripping/reclosing with 24 inputs & 46 outputs (4 fast output contacts) K
1 & 3 Pole tripping/reclosing with 24 inputs & 46 outputs (8 fast output contacts) L
Protocol options
K-Bus 1
Modbus 2
VDEW (IEC 60870-5-103) (RS485 or Fibre Optic) 3
DNP3.0 4
UCA2 5
IEC61850 + Courier via rear RS485 port * 6
IEC61850 + IEC60870-5-103 via rear RS485 port
* 7
DNP3 over Ethernet with Courier rear port K-Bus/RS485 protocol
8
* NB: IEC61850 Edition 2 available with '82' Software
Mounting
Flush/Panel Mounting with Harsh Environment Coating M
19" Rack Mounting with Harsh Environmental Coating N
Language
English, French, German, Spanish 0
English, French, German, Italian 4
C
Software version
Date and application dependant
Customer specific options
Standard version 0
Customer engineered version: ENEL 1
Customer engineered version: TERNA 2
Customer engineered version: RTE 4
Customer engineered version: General A
Hardware version
Model and hardware version dependant *
Variants Order No.
Chinese, English or French via HMI, with English or French only via Communications port
Non-conventional input transformers NCIT (IEC 61850-9-2 LE) NEW BOARD
