Ordinal English Text Description Source
194 AR Lockout Shot>
Autoreclose lockout following final programmed attempt:
Indicates a failed autoreclose (definitive trip following the
last reclosing shot). The relay will be driven to lockout
and the autoreclose function will be disabled until the
lockout condition has been reset. An alarm, "AR Lockout
Shots>" (along with AR Lockout) will be raised.
1 = 'A/R Enable' &
[('1Ptrip & No 'SPAR Enable') + (3P Trip & No 'TPAR
enable)
+ ('1P Trip' + '3P Trip') & (Number of shots=setting)]
PSL (OUT)
Autorecloser
195 SG-opto Invalid Setting group (selected via opto inputs 1 & 2) invalid PSL (OUT)
196 A/R Fail
No check sync / autorecloser failed: If the check sync
conditions are not met prior to reclosing within the time
window, the 'A/R Fail' alarm will be raised.
PSL (OUT)
Autorecloser
197 V<1 Alarm 1st stage undervoltage alarm picks up when V<1 starts
PSL (OUT)
V<1
198 V<2 Alarm
2nd stage undervoltage alarm picks up when V<21
starts
PSL (OUT)
V<2
199 V>1 Alarm 1st stage overvoltage alarm picks up when V>1 starts
PSL (OUT)
V>1
200 V>2 Alarm 2nd stage overvoltage alarm picks up when V>2 starts
PSL (OUT)
V>2
201 COS Alarm HF carrier anomaly alarm (Carrier out of service)
PSL(OUT)
Unblocking
logic
202 Brok. Cond. Alarm Broken Conductor Alarm
PSL(OUT)
Broken
conductor
203 CVT Alarm
Alarm for capacitive voltage Transformer: Indicates the
residual voltage is greater than the threshold adjusted in
the settings, during a time-delay greater than the
adjustment. That alarm is also included in the general
alarm.
PSL (OUT)
204 NCIT Alarm
Relays with IEC 61850 9-2 Ethernet board only
(software version D5.x)
IEC 61850 9-2 Alarm - Frame from Merge Units
missing. If two consecutive of any Logical Node frames
have not been received within the Merge Unit Delay set
parameter (time of silence in the reception of the frame),
the LN is “absent”
PSL (OUT)
205 Val/Fail Acq Al.
Relays with IEC 61850 9-2 Ethernet board only with
software version up to D4.x
Alarm NCIT (9-2 Ethernet) - Frame from Merge Units
failed.
Any Logical Node is synchronized with Internal (local)
synchronization
PSL (OUT)
205 -- Unused (software version D5.x)
206 Test Mode Acq
Relays with IEC 61850 9-2 Ethernet board only with
software version up to D4.x - Any Logical Node is in
“Test Mode”
PSL (OUT)
206 -- Unused (software version D5.x)
207 Synchro Acq Al.
Relays with IEC 61850 9-2 Ethernet board only with
software version up to D4.x - Any Logical Node is
synchronized with external (global) synchronization
PSL (OUT)
207 -- Unused (software version D5.x)
208 alarm user 1 Alarm user for dedicated PSL PSL(IN)
209 alarm user 2 Alarm user for dedicated PSL PSL(IN)
210 alarm user 3 Alarm user for dedicated PSL PSL(IN)
211 alarm user 4 Alarm user for dedicated PSL PSL(IN)
212 alarm user 5 Alarm user for dedicated PSL PSL(IN)
