Ordinal English Text Description Source
233 A/R TPAR Enable
Three pole autorecloser (TPAR) activated: If it is
assigned to an opto input in the PSL (by default, the PSL
is inverted and linked to opto 8) and energized, the
DDB:'A/R TPAR Enable' will enable the 3-pole
autoreclose logic (the priority is higher than the 'CB
Control / A/R three pole' setting) - this means the 3-pole
autoreclose logic can be disabled even if it has been
activated; if the relevant opto input is not energised (to
be valid, the opto input must be energised for over 1.2s).
NOTE: After a new PSL has been downloaded to the
relay (including the "TPAR" or "SPAR" cells); the
settings configuration must be uploaded back (from PC
to relay) to update the data in the RAM and the
EEPROM (otherwise discrepancies could appear in the
“AR enable” logic sate).
Set to 1: 3P AR activated (copy of 'TPAR enable' opto
input OR 'CB Control/ A/R Three pole' enabled)
Reset to 0: if 'TPAR enable' = 0 OR ('A/R Three pole'
disabled)
PSL (OUT)
Autorecloser
234 A/R Lockout
Autorecloser locked-out (no autoreclosure possible until
reset),
If protection operates during the reclaim time, after the
final reclose attempt, the relay will be driven to lockout
and the autoreclose function will be disabled until the
lockout condition is reset. This will produce an alarm:
A/R Lockout. Then, the DDB:'BAR' input will block the
autorecloser and cause a lockout if a reclose cycle is in
progress. Lockout will also occur if the CB energy is low
and the CB fails to close. Once the autorecloser is
locked out, it will not function until a Reset Lockout or
CB Manual Close command is received (depending on
the Reset Lockout method chosen in CB Monitor Setup).
NOTE: Lockout can also be caused by the CB condition
monitoring functions maintenance lockout, excessive
fault frequency lockout, broken current lockout, CB failed
to trip and CB failed to close, manual close no check
synchronism and CB unhealthy.
Set to 1 = 'A/R Enable'
AND [ ('BAR' =1 (see internal logic)
OR
'A/R lockout shot> (AR lockout by number of shots)
OR
(No CB Healthy at the end of Inhibit Window (setting))
OR
(No 'CB discrepancy' (opto input or internal by CBAux if
present in PSL) at the end of 1P Dead time1)
OR
Trip 1P or3P maintained / still present at the end
of the1P or 3P Dead time) or after discrimination
time-delay if a 3-pole trip occurs during a 1-Pole AR
Cycle ]
At 0: AR activated
Reset to 0 = ('Reset 1P Trip' OR 'Reset 3P Trip') AND
(End of reclaim time) AND Reset (BAR) AND Reset (A/R
lockout shot>) AND Reset (No CB Healthy) AND Reset
(No Discrepancy)
PSL (OUT)
Autorecloser
235 A/R Force Sync.
Force synchronism check to be made (simulate the
CheckSync control and forces the DDB:'CheckSync OK'
(logic output) to 1 during a 1-pole or 3-pole high speed
autoreclose cycle)
The signal is reset with A/R reclaim
PSL (OUT)
Autorecloser
