GE P444 - Page 359

Programmable Logi
c P44x/EN PL/Hb
6
MiCOM 40 Agile P442, P444
(PL) 6-
39
Ordinal English Text Description Source
1079 DIST. Tim. Block
Block distance element time delay
At 1: The distance timer will be blocked & DIST will
start but will not perform a Trip command.
Reset to 0: Opto input power off if signal assigned to
an opto input
OR DDB at 0 if signal assigned to a DDB cell
PSL (IN)
Distance
1039 Ext Chk Synch OK
Authorization signal from external check Synchroniser
(via opto input, with a dedicated PSL) for reclosing with
internal autoreclose (indicates that Check Sync
conditions are met by an external device – The DDB
cell should be assigned afterwards an internal AR
logic),
If an opto input is assigned in the PSL, the autoreclose
close command will be verified by an external check
synchronism device. The input is energised when the
Check Sync conditions are met.
PSL (IN)
Autorecloser
1046 External Trip A
Phase A trip by external protection relay. This input
can be used to update the CB condition monitoring.
Opto input is assigned to External Trip A (external Trip
command issued by main 2 or to initiate the internal
A/R backup protection). External trip is integrated in
the DDB: 'Any Trip'. As for an internal trip, no dwell
timer is associated to it.
PSL (IN)
1047 External Trip B
Phase B trip by external protection relay. This input
can be used to update the CB condition monitoring.
Opto input is assigned to External Trip B (external Trip
command issued by main 2 or to initiate the internal
A/R backup protection). External trip is integrated in
the DDB: 'Any Trip'. As for an internal trip, no dwell
timer is associated to it.
PSL (IN)
1048 External Trip C
Phase C trip by external protection relay. This input
can be used to update the CB condition monitoring.
Opto input is assigned to External Trip C (external Trip
command issued by main 2 or to initiate the internal
A/R backup protection). External trip is integrated in
the DDB: 'Any Trip'. As for an internal trip, no dwell
timer is associated to it.
PSL (IN)
428 F Inhib Frequency Inhibition PSL
176 F out of Range
Frequency tracking does not work correctly (provides a
Frequency Out-of-Range indication)
PSL (OUT)
187 F.F. Lock
Excessive Fault Frequency CB Trip pre lockout Alarm
(maximum number of fault): An alarm is issued at (n)
value in the counters of Main lock out or Fault
frequency
PSL (OUT)
CB
monitoring
186 F.F. Pre Lockout
Excessive Fault Frequency CB Trip lockout Alarm
(maximum number of fault): An alarm is issued at (n-1)
value in the counters of Main lock out or Fault
frequency
PSL (OUT)
CB
monitoring
416 F<1 Start Underfrequency stage 1 start PSL
1100 F<1 Timer Block Timer block underfrequency stage 1 PSL (IN)
422 F<1 Trip Underfrequency stage 1 trip PSL
417 F<2 Start Underfrequency stage 2 start PSL
1101 F<2 Timer Block Timer block underfrequency stage 2 PSL (IN)
423 F<2 Trip Underfrequency stage 2 trip PSL
418 F<3 Start Underfrequency stage 3 start PSL
1102 F<3 Timer Block Timer block underfrequency stage 3 PSL (IN)
424 F<3 Trip Underfrequency stage 3 trip PSL
419 F<4 Start Underfrequency stage 4 start PSL
1103 F<4 Timer Block Timer block underfrequency stage 4 PSL (IN)
