GE P444

Commissioning
P44x/EN CM/Hb
6
MiCOM P40 Agile P442, P444
(CM) 9-
15
Relay 4 H7-H9 H8-H9 Relay 15 - F1-F2
Relay 5 H10-H12 H11-H12 Relay 16 - F3-F4
Relay 6 H13-H15 H14-H15 Relay 17 - F5-F6
Relay 7 H16-H18 H17-H18 Relay 18 F7-F9 F8-F9
Relay 8 - G1-G2 Relay 19 F10-F12 F11-F12
Relay 9 - G3-G4 Relay 20 F13-F15 F14-F15
Relay 10 - G5-G6 Relay 21 F16-F18 F17-F18
Relay 11 G7-G9 G8-G9
With high break relay board (model P442×××C)
Output N/C N/O Output N/C N/O
Relay 1 - H1-H2 Relay 10 - G5-G6
Relay 2 - H3-H4 Relay 11 G7-G9 G8-G9
Relay 3 - H5-H6 Relay 12 G10-G12 G11-G12
Relay 4 H7-H9 H8-H9 Relay 13 G13-G15 G14-G15
Relay 5 H10-H12 H11-H12 Relay 14 G16-G18 G17-G18
Relay 6 H13-H15 H14-H15 HB relay 15 - F3(–)-F4
Relay 7 H16-H18 H17-H18 HB relay 16 - F7(–)-F8(+)
Relay 8 - G1-G2 HB relay 17 - F11(–)-F12(+)
Relay 9 - G3-G4 HB relay 18 - F15(–)-F16(+)
MiCOM P444
Output N/C N/O Output N/C N/O
Without high break relay board (all models except P444×××C)
Relay 1 - M1-M2 Relay 24 K16-K18 K17-K18
Relay 2 - M3-M4 Relay 25 - J1-J2
Relay 3 - M5-M6 Relay 26 - J3-J4
Relay 4 - M7-M8 Relay 27 - J5-J6
Relay 5 - M9-M10 Relay 28 - J7-J8
Relay 6 - M11-M12 Relay 29 - J9-J10
Relay 7 M13-M15 M14-M15 Relay 30 - J11-J12
Relay 8 M16-M18 M17-M18 Relay 31 J13-J15 J14-J15
Relay 9 - L1-L2 Relay 32 J16-J18 J17-J18
Relay 10 - L3-L4 Relay 33 - H1-H2
Relay 11 - L5-L6 Relay 34 - H3-H4
Relay 12 - L7-L8 Relay 35 - H5-H6
Relay 13 - L9-L10 Relay 36 H7-H9 H8-H9
Relay 14 - L11-L12 Relay 37 H10-H12 H11-H12
Relay 15 L13-L15 L14-L15 Relay 38 H13-H15 H14-H15
Relay 16 L16-L18 L17-L18 Relay 39 H16-H18 H17-H18
Relay 17 - K1-K2 Relay 40 - G1-G2
Relay 18 - K3-K4 Relay 41 - G3-G4
Relay 19 - K5-K6 Relay 42 - G5-G6
Relay 20 - K7-K8 Relay 43 G7-G9 G8-G9
Relay 21 - K9-K10 Relay 44 G10-G12 G11-G12
Relay 22 - K11-K12 Relay 45 G13-G15 G14-G15
Relay 23 K13-K15 K14-K15 Relay 46 G16-G18 G17-G18
With high break relay board (model P444×××C)
Relay 1 - M1-M2 HB relay 18 - J7(–)-J8(+)
Relay 2 - M3-M4 HB relay 19 - J11(–)-J12(+)
