GE P444

Troubleshooting
P44x/EN TS/Hb
6
MiCOM P40 Agile
P442, P444 (TS) 11-
11
Hex Code
Decimal Code
Meaning
0x0C160012 202768402
The continuous self-checks have found an error in the
Flash EPROM checksum. Check the Flash EPROM on the
main processor board, and then try downloading a new
program.
0x0C160013 202768403
The continuous self-
checks have found an error in the code
comparison. Check the Flash EPROM on the main
processor board, and then try downloading a new program.
0x0C160014 202768404
The continuous self-checks have found an error in the
battery backed SRAM. Check the battery, then the RAM on
the main processor board.
0x0C160015 202768405
The continuous self-checks have found an error in the
EEPROM. Check the EEPROM on the main processor
board.
0x0C1600A0 202768544
The continuous self-checks have found an error on the
acquisition board. Check the input board.
0x0C1600B0 202768560
The continuous self-checks have found an error on the
relay board. Check the relay board.
0x0C1600C0 202768576
The continuous self-checks have found an error on an
opto-imput board. Check the opto-input board.
0x0C170016 202833942
Secondary initialisation tests detected a fast watchdog
failure. Check the Flash EPROM on the main processor
board.
0x0C170017 202833943
Secondary initialisation tests detected a battery backed
SRAM failure. Check the battery backed SRAM on the
main processor board.
0x0C170018 202833944
Secondary initialisation tests detected a bus reset test
failure. Check the main processor board.
0x0C170019 202833945
Secondary initialisation tests detected a slow watchdog
failure.
0x0E020000 235012096
The number of logic gates in the PSL exceeds allowed
number. Check and correct the PSL.
0x0E080000 235405312
The execution of the PSL logic exceeds available time.
Check and correct the PSL.
0x8182xxxx
2122252288 to
2122186753
Error code in the commissioning test module. Check the
processor board.
0x93830000 1820131328 Software in
0x93840000 1820065792
The check of the SRAM has failed. Check the differential
current board.
0x93860000 1819934720 The program does not start. Check the opto-input board.
0x93870000 1819869184
Bad number of opto-inputs. Check the Opto-input board
and model number.
0xAC810000 1400832000 Opto-input software stopped
Table 5: Error Codes
Other error codes relate to problems within the main processor board software. Contact the
General Electric Contact Centre at www.gegridsolutions.com with details of the problem for a
full analysis.
