GE P444

P
44x/EN ST/Hb6
Setting
(ST) 4
-12 MiCOM P40 Agile
P442, P444
Binary State of SG Change bit 1
Opto 2
Binary State of SG Change bit 0
Opto 1
Se
tting Group
Activated
0 0 1
0 1 2
1 0 3
1 1 4
Table 1 - Setting Group Selection
REMINDER: IF SELECTED IN THE MENU (CHANGE BY OPTOS), OPTO 1 & 2 MUST
BE REMOVED FROM THE PSL (THEY ARE DEDICATED TO GROUP
SELECTION)
