GE P444

P
44x/EN ST/Hb6
Setting
(ST) 4
-14 MiCOM P40 Agile
P442, P444
Menu text Default setting
Setting range
Step size
Min Max
GROUP 1 – DISTANCE ELEMENTS
Z1X
15/In Ω 0.001/In Ω 500/In Ω 0.001/In Ω
R1G
10/In Ω
0
400/In Ω 0.01/In Ω
R1G: Resistive reach (Earth fault element, refer to P44x/EN AP for resistive reach
calculation (earth and phase) setting).
R1Ph
10/In Ω
0
400/In Ω 0.01/In Ω
R1Ph: Resistive reach (phase fault element, refer to P44x/EN AP for resistive reach
calculation (earth and phase) settings).
tZ1 0 0 10s 0.002s
Zone 1 time delay (TZ1): Zone 1 time delay setting (refer to P44x/EN AP for setting).
KZ2 Res Comp 1 0 7 0.001
KZ2 Angle 0° 0° 360° 0.1°
Zone 2 compensation (KZ2 residual compensation and kZ2 angle) setting.
Z2
20/In Ω 0.001/In Ω 500/In Ω 0.001/In Ω
R2G
20/In Ω
0
400/In Ω 0.01/In Ω
R2G: resistive reach – Earth fault element setting for zone 2.
R2Ph
20/In Ω
0
400/In Ω 0.01/In Ω
R2Ph: Resistive reach – phase fault elements setting for zone 2.
tZ2 0.2s 0 10s 0.01s
Zone 2 time delay (TZ2) setting.
KZ3/4 Res Comp 1 0 7 0.01
KZ3/4 Angle 0° 0° 360° 0.1°
Zone 3 and 4 compensations (KZ3/4 residual compensation and kZ3/4 angle) setting.
Z3
30/In Ω 0.001/In Ω 500/In Ω 0.001/In Ω
R3G - R4G
30/In Ω
0
400/In Ω 0.01/In Ω
R3G – R4G: Resistive reach – Earth fault elements setting for zones 3 and 4.
R3Ph - R4Ph
30/In Ω
0
400/In Ω 0.01/In Ω
R3Ph – R4Ph: resistive reach – Phase fault elements setting for zones 3 and 4.
tZ3 0.6s 0 10s 0.01s
Zone 3 time delay (TZ3) setting.
Z4
40/In Ω 0.001/In Ω 500/In Ω 0.01/In Ω
tZ4 1s 0 10s 0.01s
Zone 4 time delay (TZ4) setting.
Zone P - Direct. Directional Fwd Directional Fwd or Directional Rev
KZp Res Comp 1 0 7 0.001
KZp Angle 0° 0° 360° 0.1°
Zone P compensation (KZp residual compensation and kZp angle).
Zp
25/In Ω 0.001/In Ω 500/In Ω 0.001/In Ω
