GE P743 User Manual

Programmable Logic
P74x/EN PL/N
a7
MiCOM P74
1, P742, P743
(PL) 7-
23
PL
Relay
DDB
No.
English Text Type Source Description
P741
1087
virtual input 64
GOOSEIN
GOOSE Input
Command
Virtual Input 64
Allows binary signals that are mapped to virtual
inputs to interface into PSL
P741
543
Virtual Output 32
GOOSEOUT
PSL
GOOSE Output 32
Allows user to control a binary signal which can
be mapped via SCADA protocol output to other
devices
P741
512
Virtual Output 1
GOOSEOUT
PSL
GOOSE Output 1
Allows user to control a binary signal which can
be mapped via SCADA protocol output to other
devices
1.8 Description of P742 logic nodes
1.8.1 Sorted by DDB number
Relay
DDB
No.
English Text Type Source Description
P742
0
Relay Label 01
RELAY
Output Conditioner
Output Relay 01 - All trips (FSL) but not retrip
P742
1
Relay Label 02
RELAY
Output Conditioner
Output Relay 02 - All trips (FSL) but not retrip
P742
2
Relay Label 03
RELAY
Output Conditioner
Output Relay 03 - All trips (FSL) but not retrip
P742
3
Relay Label 04
RELAY
Output Conditioner
Output Relay 04
P742
7
Relay Label 08
RELAY
Output Conditioner
Output Relay 08
P742
64
Opto Label 01
OPTO
Opto Input
Opto Input 1
P742
79
Opto Label 16
OPTO
Opto Input
Opto Input 16
P742
96
LED 1
LED
Led Conditioner
Red LED 1
P742
103
LED 8
LED
Led Conditioner
Red LED 8
P742
104
Q1 Aux. (89b)
PSL Output
Signal
PSL
89-B (Isolator open) Auxiliary Input (3 phase) of
the isolator 1
P742
105
Q1 Aux. (89a)
PSL Output
Signal
PSL
89-A (Isolator closed) Auxiliary Input (3 phase)
of the isolator 1
P742
114
Q6 Aux. (89b)
PSL Output
Signal
PSL
89-B (Isolator open) Auxiliary Input (3 phase) of
the isolator 6
P742
115
Q6 Aux. (89a)
PSL Output
Signal
PSL
89-A (Isolator closed) Auxiliary Input (3 phase)
of the isolator 6
P742
116
Ext. 3 ph Trip
PSL Output
Signal
PSL (50BF
protection)
External 3 phase Trip
Allows external protection to initiate breaker fail
(if enabled)
P742
117
External Trip A
PSL Output
Signal
PSL (50BF
protection)
External 3 phase A Trip
Allows external protection to initiate breaker fail
(if enabled)
P742
118
External Trip B
PSL Output
Signal
PSL (50BF
protection)
External 3 phase B Trip
Allows external protection to initiate breaker fail
(if enabled)
P742
119
External Trip C
PSL Output
Signal
PSL (50BF
protection)
External 3 phase C Trip
Allows external protection to initiate breaker fail
(if enabled)
P742
120
Man.CB Close
Cmd
PSL Output
Signal
PSL
Manual/operator Circuit Breaker trip command
P742
121
CB not available
PSL Output
Signal
PSL
Circuit Breaker is not available to trip
P742
122
Ext. CB Fail
PSL Output
Signal
PSL (50BF Backtrip
protection)
50BF Backtrip order from an other protection
P742
123
CB Aux. 3ph(52a)
PSL Output
Signal
PSL
52-A (CB closed) CB Auxiliary Input (3 phase)
P742
124
CB Aux. 3ph(52b)
PSL Output
Signal
PSL
52-B (CB open) CB Auxiliary Input (3 phase)
P742
125
CB Aux. A (52a)
PSL Output
Signal
PSL
52-A (CB closed) CB Auxiliary Input (phase A)
P742
126
CB Aux. A (52b)
PSL Output
Signal
PSL
52-B (CB open) CB Auxiliary Input (Phase A)
P742
127
CB Aux. B (52a)
PSL Output
Signal
PSL
52-A (CB closed) CB Auxiliary Input (phase B)
P742
128
CB Aux. B (52b)
PSL Output
Signal
PSL
52-B (CB open) CB Auxiliary Input (Phase B)
P742
129
CB Aux. C (52a)
PSL Output
Signal
PSL
52-A (CB closed) CB Auxiliary Input (phase C)
P742
130
CB Aux. C (52b)
PSL Output
Signal
PSL
52-B (CB open) CB Auxiliary Input (Phase C)
P742
131
Reset Trip latch
PSL Output
Signal
PSL
(Commissioning)
Reset Latched Relays
