Basic scanning operations
Vivid S5/Vivid S6 User Manual 113
R2424458-100 Rev. 2
Storing images and cineloops
Images stored on
the clipboard dur-
ing the scanning
session are for im-
mediate purposes.
At the end of the ex-
amination, the data
should be archived
in the patient ar-
chiving system (re-
fer to page 403).
Images and cine-loops can be stored at any time during the
scanning session. A thumbnail of the stored image is displayed
on the clipboard on the scanning screen. An icon will also be
displayed in the Image Browser and Image Selection screens.
Protocol based stored images (Stress option) will also be
displayed in the protocol grid in the Parameters window.
The amount of data stored from 2D live is defined by the
settings of the current application. The application setting
controls the number of cycles included (or time span if ECG is
not active), time span before R-wave etc. (refer to page 590
and page 593 for further information).
The amount of data stored in images from 2D replay is
determined by the defined cineloop.
Images can be stored in either DICOM and GE Raw Data
formats or DICOM format only, depending on the dataflow
configuration (refer to page 616 for further information).
To store a single image
1. Press FREEZE.
2. Press
STORE to store the image digitally.
The thumbnail of the image is displayed on the clipboard.
See also page 406 for further information.
To store a cineloop
While in scanning mode, press the STORE button to store the
last heart-cycle loop. It is possible to configure this function in
several ways. Cineloops may be stored directly or after
preview, depending on how the system is configured.
While in cine-loop preview mode press
STORE to store the
selected loop.
Cineloop length and loop selection is adjustable in several
ways. The procedure for cineloop storage is described on
page 406.
