Measurement and Analysis
Vivid S5/Vivid S6 User Manual 249
R2424458-100 Rev. 2
Entering a study and performing
measurements
Note: When enter-
ing the Measure-
ment mode for the
first time, the Cali-
per tool is selected
by default.
1. Press MEASURE on the front panel to enter the Assign and
Measure modality.
The Measurement menu with a list of studies is displayed
in the Parameters window (see example Figure 7-2).
When re-entering
the Measurement
mode, the first mea-
surement in the ac-
tual study that has
not been performed
is selected by de-
fault.
2. Select any required study (other than Generic study which
is reserved for the Measure and Assign modality).
3. Within the selected study, select the required parameter
which you intend to measure.
4. Perform the measurement. The parameter’s name and
measured value will appear in the result window.
To perform a measurement from another study
1. Trackball to the required study.
2. Press
SET on the trackball area.
The study folder is opened displaying the measurements
related to this study. Other related studies may also be
available from within the study.
3. Trackball to the measurement to perform.
4. Press
SET on the trackball area to activate the
measurement tool.
The cursor is moved back to the scanning window.
5. Perform the measurement.
Completed measurements are marked with a check mark
(Figure 7-2).
When the measurement operation is completed the next
measurement on the list is automatically selected.
To skip a measurement in a study
1. Trackball to the desired measurement
2. Press
SET to activate the measurement tool.
To Next Page
