GE Vivid S5 User Manual

Measurement and Analysis
Vivid S5/Vivid S6 User Manual 321
R2424458-100 Rev. 2
Selecting probe and OB application
Select probe and application as described on "Starting an
examination" on page 95.
• For a first-trimester OB exam select OB1.
• For a second / third trimester OB exam select OB2/3.
The following presets are available in addition:
• OB General
• Fetal Heart
• OB/GYN Vessel
Note: The selection of the OB preset will not only optimize the
imaging but will also bring up the proper M&A package for that
particular application.
The parameter contents of each of the applications are
configurable by the operator. Following are the factory presets
for each of the applications.
OB1 application
The measurements available by default for OB1 are:
OB2/3 application
The measurements available by default for OB2/3 are:
GS (Hellman)
CRL (Hadlock)
BPD (Hadlock)
FL (Hadlock)
AC (Hadlock)
HC (Hadlock)
BPD (Hadlock)
FL (Hadlock)

GE Vivid S5 Specifications

General

Type	Ultrasound System
Power Supply/Requirements	100-240 VAC, 50/60 Hz
Display	15-inch LCD
Imaging Modes	2D, Color Doppler, M-Mode
Operating Temperature	10°C to 40°C (50°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	30% to 85% (non-condensing)
Application	Cardiology
Transducer Options	Phased Array, Linear Array, Convex Array, TEE
