15
GEEETECH
NO.62
1
Stepper motor
NO.44
1
Pulley
NO.26
3
M3 x 12 screw
NO.27
2
M3 x 20 screw
NO.17
2
M3 square nut
Step1. Mount the pulley on the motor shaft, one of the screws should be screwed on
the cross section of the shaft. Screw it as tight as possible.
