57
GEEETECH
21 Assemble the Z axis top mount
Watch the video
Part name
Part ID
Required number
pic
Z top mount
No.A8
2
M3 x 16mm screw
No.27
4
M3 Square nut
No.17
4
locking ring
No.20
2
