24
GEEETECH
9 Assemble the right and left side panel
Watch the video
Pic
Part ID
Required number
Required parts
NO.A1
1
XZ frame
NO.A2
1
Acrylic left frame
NO.A3
1
Acrylic right
frame
NO.27
6
M3 x 16 screw
