32
GEEETECH
13 Mount the End stop of Z-axis
Watch the video
Pic
Part ID
Required number
Required parts
NO.56
1
End stop
NO.22
2
M 2.5 X 16 screw
NO.10
2
M 2.5 nut
Mount the endstop on the outside of A7 with M2.5 x 16mm screw and M2.5 hex nut.
