44
GEEETECH
18 Assemble the right end of the X axis. (X idler end)
Watch the video
Part name
Part ID
Required number
pic
Z-axis nut
No.18
1
X-axis idle end
No.M2
1
Linear Bearing
LMH8LUU
No. 38
1
