23
GEEETECH
8 mount the End stop of Y-axis
Watch the video
Pic
Part ID
Required number
Required parts
NO.56
1
End stop
NO.22
2
M2.5 x 16 screw
NO.10
2
M2.5 Hex nut
Mount the end stop on the rear support plate of Y axis with M2.5 X 16 screw and
M2.5 Hex nut.
