Geeetech Prusa I3 Pro C User Manual

50
GEEETECH
Mount it on the carriage with an M3x8mm screw and a M3 hex nut.
20 Assemble the X&Z axis
Watch the video
Part name
Part ID
Required number
pic
L300mm threaded
rod
No.4
2
L322mm smooth
rod
No.1
2
L410mm smooth
rod
No.3
2
locking ring
No.20
4
Step1. Thread the L300 threaded rod to the nut of both end of X axis.
Keep both end of X axis at the same place of the rod, you are advised to measure the
