Geeetech Prusa I3 Pro C - Assemble Y-Z Axis

26
GEEETECH
10 Mount the fan
Watch the video
Pic
Part ID
Required
number
Required parts
NO.53
1
Fan
NO.29
4
M3 x 30 screw
NO.14
4
M3 locknut
Fix the fan on the right side of the frame with 4 M3 x 30 screw and lock nut. Mind the
direction of the wires. (Please pay attention to the direction of the fan)
If you don’t want to use the lock nut you can use hex nut.
