68
GEEETECH
*Note the direction of the driving wheel, the side with bolt head should be towards the
A1, or it will scratch the acrylic plate.
25 Mount the LCD panel frame
Watch the video
Pic
Part ID
Required number
Required parts
NO.65
1
LCD 2004
NO.A18
1
LCD frame
NO.A19
2
LCD frame holder
NO.A17
4
Acrylic washer
NO.28
6
M3 x 20 screw
NO.11
4
M3 nut
NO.52
1
Knob
