30
GEEETECH
12 Assemble Y - Z axis
Watch the video
Pic
Part ID
Required number
Required parts
NO.27
2
M3 x 16 screw
NO.28
4
M3 x 20 screw
NO.11
4
M3 nut
NO.17
2
M3 square nut
Step1. Put the Y axis into the main frame.
