Geeetech Prusa I3 Pro C - Page 42

38
GEEETECH
NO.48
4
clamp
NO.16
4
Wing nut
NO.60
1
Borosilicate glass
*All our heated bed is pre-soldered or attached before shipping; you can attach the
bed directly here.
Mount the heat bed on the platform with 4 M3 x35 screws and wing nuts with springs
in between. Clamp the heat bed and the glass sheet.
*the soldered side is better to be attached downwards.
