62
GEEETECH
M3 x40mm screw
No.31
1
M4 x 25mm screw
No.33
1
M3 washer
No.7
1
M4 washer
No.8
1
M4 lock nut
No.15
1
wing nut
No.16
1
Step1. Thread the M3 x 40 screw and M3 washer through the Driven wheel holder.
Step2. Insert the two MR84zz ball bearings into both ends of the driving wheel.
