ADV200 SP • Quick start up guide - Specification and installation 23
5.1.5 Power line connection
Isolated systems, PV alone:
ADV200 SP-1015 ... 61600 ADV200 SP-3220-DC... 61600-DC
350 ... 750Vcc
SPD
PV generator
Insulation
control
+
-
F2
K2M
350 ... 750Vcc
PV generator
Insulation
control
+
-
F2
K2M
SPD
Dual supply systems, PV or Secondary power source:
ADV200 SP-1015 ... 61600
350 ... 750Vcc
PV generator
Insulation
control
50-60Hz
3 ph - 380-480Vac
L1 L2 L3
+
-
K1M
F1 F2
K2M
SPD
Hybrids Systems, PV and Secondary power source:
ADV200 SP-1015 ... 61600
350 ... 750Vcc
PV generator
Insulation
control
50-60Hz
3 ph - 380-480Vac
L1 L2 L3
+
-
K1M
F1 F2
SPD
Note! Terminals BR1/BR2 are standard up to size ADV200 SP-3300, optional in sizes ADV200 SP-4370 ... 5750, larger sizes
are not used.
Recommended combination F1 fuses: see paragraph “10.5 Fuses”, page 95
