ADV200 SP • Quick start up guide - Specification and installation 91
10.1.3 Mounting instructions and Precautions
Assembly example
S8DI100 ... S8DI102 S8DI103 ... S8DI111
1
2
1
3
5
4
6
7
8
6
7
8
S8DI101
S8DI102
S8DI100
Rondella piana
Flat washer
1
2
1
3
4
5
Rondella piana
Flat washer
Models
BD-SP-1600V-...
Cod.
       
Hexagonal
head screw
(N2)
Insulator
(thread)
Hexagonal
head screw
(N2)
Round
terminal
Nut
(N2)
Nut
(N2)
Round
terminal
Screw
-50A/100C S8DI100 4 x M8 2 (M8) 1 x M6 1 x M6 1 x M6 1 x M4 1 x M4 1 x M4
-50A/70C-150A/100C S8DI101 4 x M8 2 (M8) 1 x M8 1 x M8 1 x M8 1 x M8 1 x M8 1 x M8
-150A/70C-200A/100C S8DI102 4 x M8 2 (M8) 1 x M8 1 x M8 1 x M8 1 x M10 1 x M10 1 x M8
-200A/70C-300A/100C S8DI103 8 x M6 4 (M6)
(N1)
x M6
(N1)
x M6
(N1)
x M6 - - -
-300A/70C-400A/100C S8DI104
8 x M8 4 (M8)
(N1)
x M8
(N1)
x M8
(N1)
x M8 - - -
-400A/70C-450A/100C S8DI105
-450A/70C-500A/100C S8DI106
-500A/70C-600A/100C S8DI107
-600A/70C-700A/100C S8DI108
-700A/70C-800A/100C S8DI109
-800A/70C-1000A/100C S8DI110
-1000A/70C-1500A/100C S8DI111
(N1)
The amount must be calculated taking into account the maximum DC current and the related cable section(s).
(N2)
Suggested tightening torque: M6=5Nm, M8=12Nm, M10=25Nm.
Temperature
The device has metal parts (heat sinks) that can reach dangerous temperatures.



Warning!
