74 ADV200 SP • Quick start up guide - Specification and installation
Sizes
I
n Rated output current (For Asynchronous motors)
@U
ln=400Vac @Uln=460Vac
Heavy duty
(A)
Light duty
(A)
Heavy duty
(A)
Light duty
(A)
5900 150 180 135 162
51100 180 210 162 189
61320 210 250 189 225
61600 250 300 225 270
Sizes
ADV200
SP-DC
I
n Rated output current (For Asynchronous motors)
@540
Vdc
Heavy duty
(A)
@540
Vdc
Light duty
(A)
@650
Vdc
Heavy duty
(A)
@650
Vdc
Light duty
(A)
3220 38 46 34.2 41.4
3300 46 62 41.4 55.8
4370 62 75 55.8 67.5
4450 75 87 67.5 78.3
4550 87 105 78 94,5
5750 105 150 94.5 135
5900 150 180 135 162
51100 180 210 162 189
61320 210 250 189 225
61600 250 300 225 270
9.6.1 Output current derating factors
Output current derating factors
I = I
1
K
1
(1)
: Derating factor for mains voltage from 46to 48
K
(2)
K
(3)
I.e.: Altitude 2000 m, K derated = 100 - ((12*100)/100) = 88 % I
K
(4)
: Derating factor for higher switching frequency
If not all of the derating factors are considered, this could result in a drive overtemperature condition.
Sizes
Derating factor KV
1 (1)
@Uln=400Vac @Uln=460...480Vac
Tamb = 40°C
from AFE200
Tamb ≤ 30°C Tamb = 40°C
from AFE200
Tamb ≤ 30°C
Tamb
31 ... 40°C
Tamb ≤ 30°C
Tamb 3
1 ... 40°C
1015 ... 61600 1 1 0.9 1 0.9 0.9 0.81
Sizes
f
sw
Switching frequency
Derating factor
Default Higher
K
t KAlt Kf (4)
(2) (3)
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 Hz
1015 8 10, 12 0.9 1.2 1 1 1 1 0.85 0.7
1022 8 10, 12 0.9 1.2 1 1 1 1 0.85 0.7
