ADV200 SP • Quick start up guide - Specification and installation 99
Sizes
AC Input voltage 400V-480V, System earthing IT
Heavy Duty Low Duty
EN 61800-3
Category
Model Code Model Code
1015 FN 2200B-25-33 FN 2200B-25-33 C4
1022 FN 2200B-25-33 FN 2200B-25-33 C4
1030 FN 2200B-25-33 FN 2200B-25-33 C4
1040 FN 2200B-25-33 FN 2200B-25-33 C4
1055 FN 2200B-25-33 FN 2200B-25-33 C4
2075 FN 2200B-25-33 FN 2200B-25-33 C4
2110 FN 2200B-25-33 FN 2200B-25-33 C4
2150 FN 2200B-25-33 FN 2200B-50-34 C4
3185 FN 2200B-50-34 FN 2200B-50-34 C4
3220 FN 2200B-50-34 FN 2200B-50-34 C4
3300 FN 2200B-75-34 FN 2200B-75-34 C4
4370 FN 2200B-100-35 FN 2200B-100-35 C4
4450 FN 2200B-100-35 FN 2200B-100-35 C4
4550 FN 2200B-100-35 FN 2200B-150-40 C4
5750 FN 2200B-150-99 FN 2200B-250-99 C4
5900 FN 2200B-250-99 FN 2200B-250-99 C4
51100 FN 2200B-250-99 FN 2200B-250-99 C4
61320 FN 2200B-250-99 FN 2200B-400-99 C4
61600 FN 2200B-400-99 FN 2200B-400-99 C4
Note!
Codes provided on request
Additional technical specifications are available from the manufacturer in the Schaffner website or catalogue
Model
Dimensions Weights
(W x H x d) - mm kg
FN 2200B-25-33 170 x 65 x 80 0,9
FN 2200B-50-34 200 x 80 x 95 1,6
FN 2200B-75-34 200 x 80 x 95 1,7
FN 2200B-100-35 220 x 95 x 125 2,7
FN 2200B-150-40 250 x 115 x 140 4,9
FN 2200B-250-99 300 x 110 x 180 5,0
FN 2200B-400-99 300 x 110 x 190 6,1
10.7 Radiation sensor
Voltage or current output ������������������������ 0 ... 20mA / 4 ... 20mA or 0 ... 10 V for connection to the ADV200 SP inverter
analog input.
