86 ADV200 SP • Quick start up guide - Specification and installation
10 - Options
10.1 DC-side diode
Note! The diodes must have a minimum blocking voltage of 1600V.
The diodes and their cooling system must be sized for the maximum currents on the DC side.
Typically, the maximum currents on the DC side are equivalent to the PV field short circuit current.
10.1.1 Diodes selection
Model Code
DC MAX current
@1600Vdc
th=70 ... 80°C
DC MAX current
@160
0Vdc
th=100 ... 110°C
Diode
connection
BD-SP-1600V-50A/100C S8DI100 - 50A Ø 4.1mm (cathode)
BD-SP-1600V-50A/70C-150A/100C S8DI101 50A 150A Ø 8.3mm (anode)
BD-SP-1600V-150A/70C-200A/100C S8DI102 150A 200A Ø 8.3mm (anode)
BD-SP-1600V-200A/70C-300A/100C S8DI103 200A 300A capsule
BD-SP-1600V-300A/70C-400A/100C S8DI104 300A 400A capsule
BD-SP-1600V-400A/70C-450A/100C S8DI105 400A 450A capsule
BD-SP-1600V-450A/70C-500A/100C S8DI106 450A 500A capsule
BD-SP-1600V-500A/70C-600A/100C S8DI107 500A 600A capsule
BD-SP-1600V-600A/70C-700A/100C S8DI108 600A 700A capsule
BD-SP-1600V-700A/70C-800A/100C S8DI109 700A 800A capsule
BD-SP-1600V-800A/70C-1000A/100C S8DI110 800A 1000A capsule
BD-SP-1600V-1000A/70C-1500A/100C S8DI111 1000A 1500A capsule
10.1.2 Diodes and weight dimensions
Model Code
Dimensions Weights
(W x H x d) - mm kg
BD-SP-1600V-50A/100C S8DI100 120 x 90 x 65 0.84
BD-SP-1600V-50A/70C-150A/100C S8DI101 120 x 120 x 100 2.1
BD-SP-1600V-150A/70C-200A/100C S8DI102 120 x 120 x 100 2.1
BD-SP-1600V-200A/70C-300A/100C S8DI103 120 x 141,6 x 126 2.7
BD-SP-1600V-300A/70C-400A/100C S8DI104 250 x 174,6 x 177 7.25
BD-SP-1600V-400A/70C-450A/100C S8DI105 250 x 174,6 x 177 7.25
BD-SP-1600V-450A/70C-500A/100C S8DI106 250 x 186 x 177 7.45
BD-SP-1600V-500A/70C-600A/100C S8DI107 250 x 186 x 177 7.45
BD-SP-1600V-600A/70C-700A/100C S8DI108 250 x 186 x 177 7.45
BD-SP-1600V-700A/70C-800A/100C S8DI109 300 x 168 x 177 9.1
BD-SP-1600V-800A/70C-1000A/100C S8DI110 300 x 224 x 240 17.2
BD-SP-1600V-1000A/70C-1500A/100C S8DI111 300 x 224 x 240 17.2
