ADV200 SP • Quick start up guide - Specification and installation 87
Figure 10.1.1: S8DI100 dimensions
65 120
90
(mm)
Ø 4.1
Figure 10.1.2: S8DI101 dimensions
120
120
100
(mm)
Ø 8.3
Figure 10.1.3: S8DI102 dimensions
120
120
100
(mm)
Ø 10.6
